Bucker SK25 Aircraft Blueprints Engineering Construction Drawings - Download
Licensed Swedish version of Bucker Bu 181 B-1 Bestmann
This collection includes 116 original blueprints covering the Bücker SK 25, the Swedish-licensed version of the Bücker Bü 181 B-1 Bestmann.
The drawings document the aircraft’s major assemblies and systems in detail — including fuselage, wings, tail, powerplant, cockpit, and technical installations.
All captions and annotations are in Swedish language .
(download PDF – 128 pages)
Breakdown as follows:
• Assembly Overview (Översiktsritningar): 3 blueprints
• Fuselage (Kropp ): 26 blueprints
• Wings (Vingar ): 15 blueprints
• Tail Assembly (Stjärt): 16 blueprints
• Powerplant (Motordrivning): 5 blueprints
• Propeller (Propeller): 8 blueprints
• Landing Gear (Landningsställ): 10 blueprints
• Systems (System): 14 blueprints
• Cockpit (Kabine): 12 blueprints
Manufacturing Documents (Tillverkningsdokument): 7 blueprints
Delivered : Download // Files Format : Adobe pdf
Disclaimer: This item is sold for historical and reference Only. These are either ORIGINAL or COPIES of manuals and blueprints used when these aircraft were in active duty, now transferred into electronic format. These manuals and blueprints are not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeller or aircraft buffs .... For proprietary reasons, we generally only provide civil manuals and blueprints on obsolete Aircraft / Engines / Helicopter. The information is for reference only, and we do not guarantee the completeness, accuracy or currency of any manuals.
