Messerschimitt Me-262 Blueprints Engineering Drawings Collection - Download

• Drawings collection includes approximately 70 factory blueprints covering the Messerschmitt Me 262. These drawings primarily document the Tail Assembly, Wings, Landing Gear, and general Assembly Overviews, with a small number of Systems drawings
  Breakdown as follows:

  Rumpfwerk (Fuselage) 30 blueprints

  Tragwerk (Wings): 10 blueprints

  Leitwerk (Tail Assembly): 11 blueprints

  Fahrwerk (Landing Gear): 4 blueprints

  Assembly Overview: 15 blueprints

  Anlagen (Systems – hydraulic, electrical, etc.): 1 blueprint

  This set of engineering drawings is not complete or exhaustive.

Disclaimer: This item is  sold  for historical and reference Only.  These are either  ORIGINAL  or COPIES of  manuals and blueprints  used when these aircraft were in active duty,  now transferred into electronic format.  These manuals  and blueprints are  not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeller or aircraft buffs ....  For proprietary reasons, we generally only provide civil manuals and blueprints on obsolete Aircraft / Engines / Helicopter. The information is for reference only, and we do not guarantee the completeness, accuracy or currency of any  manuals.

Reference herein to any specific commercial products by trade name, trademark, manufacturer, or otherwise, is not meant to imply or suggest any endorsement by, or affiliation with that manufacturer or supplier. All trade names, trademarks and manufacturer names are the property of their respective owners.

Delivered  : Download // Files Format : Adobe pdf
