Foke-Wulf Fw-190 Blueprints Engineering Drawings Collection - Downloads

• Drawings collection includes approximately 874 blueprints covering the Focke-Wulf Fw 190.
  These drawings primarily document the Fuselage, Wings, Tail, Powerplant, and general Assembly Overviews, with additional drawings for Landing Gear, Armament, Cockpit, and some obsolete blueprints.

  Note: some blueprints have annotations in English, others in German.

  Breakdown as follows:


  Assembly Overview (Montageübersicht): 19 blueprints
      • Manufacturing Documents: 152  blueprints
      • Fuselage (Rumpfwerk : 70 blueprints
      • Wings (Tragwerk ): 63 blueprints
      • Tail (Leitwerk ): 48 blueprints
      • Powerplant (Triebwerk ): 16 blueprints
      • Landing Gear (Fahrwerk): 2 blueprints
      • Armament (Bewaffnung ): 7 blueprints
      • Cockpit (Kabine ): 477 blueprints
      • Obsolete Blueprints (Überholte Zeichnungen): 20 blueprints


  This set of engineering drawings is not complete or exhaustive.

Delivered  : Download // Files Format : Adobe pdf

Disclaimer: This item is  sold  for historical and reference Only.  These are either  ORIGINAL  or COPIES of  manuals and blueprints  used when these aircraft were in active duty,  now transferred into electronic format.  These manuals  and blueprints are  not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeller or aircraft buffs ....  For proprietary reasons, we generally only provide civil manuals and blueprints on obsolete Aircraft / Engines / Helicopter. The information is for reference only, and we do not guarantee the completeness, accuracy or currency of any  manuals.

Reference herein to any specific commercial products by trade name, trademark, manufacturer, or otherwise, is not meant to imply or suggest any endorsement by, or affiliation with that manufacturer or supplier. All trade names, trademarks and manufacturer names are the property of their respective owners.
