FIAT G.55 Aircraft Blueprints Engineering Drawings - Download


Product Description

Drawings collection includes just about 26 factory blueprints  Included general layout,  details,  joints and main parts  and   CAD file in dwg  format of fusolage and wings  structure

This  set of engineering drawings are not complete or exhaustive.


Disclaimer: This item is  sold  for historical and reference Only.  These are either  ORIGINAL  or COPIES of  manuals and blueprints  used when these aircraft were in active duty,  now transferred into electronic format.  This manuals  and blueprints are  not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeler or aircraft buffs ....  For proprietary reasons we generally only provide civil manuals and blueprints on obsolete Aircrafts / Engines / Helicopter. The information is for reference only and we do not guarantee the completeness, accuracy or currency of any  manuals.

Reference herein to any specific commercial products by trade name, trademark, manufacturer, or otherwise, is not meant to imply or suggest any endorsement by, or affiliation with that manufacturer or supplier. All trade names, trademarks and manufacturer names are the property of their respective owners.

Delivered  : Download // Files Format : Adobe pdf // Compress Zipped in Rar to be uncopress with unrar


Product Reviews

Write Review

  1. Useful for design 4 Star Review

    Posted by on 23rd Feb 2021

    I found most of what I needed here for my RC scale model design. Details for making wings, stabs, surfaces, and landing gear were actual manufacturing drawings. Fuselage is a little less than expected but quite a bit there.
