Piper Aircraf Pa-11 to Pa-22 Assembly and Installation Engineering Drawings Blueprints - Download

$38.85
Quantity:

Product Description

Blueprints for Piper Aircraft Model as

Pa-11, Pa-12, Pa-14 Pa-15 Pa-16 -17 Pa-19 Pa-20, Pa-22

From the original manufacturing drawings converted first on microfilm and now in electronic  Airframe Engineering Drawings ( Blueprints )  # 481 engineering drawings sheets from # X0X  Microfilms Reels included Index of Drawings Numbers , Tiff and   Adobe PDF Graphic format .

This set include  drawings  for the systems as following

      • Fuselage assembly
      • Fuselage and airframe asembly
      • Fuselage fitting Installation
      • Instrument pannel Installation
      • Cockkpit Controls
      • Enclosure Installation
      • Seat Installation
      • Wing Installation
      • Wing Panel covered
      • Wing Panel uncovered
      • Aileron Assembly
      • Flap assembly
      • Front lift strut assembly section
      • Rear lift strut assembly section
      • Rear spar
      • Landing Gear installation
      • Landing Gear Vee
      • Tail surfaces installation
      • Fin
      • Stabilizer
      • Ruder
      • Elevator
      • Power Plant
      • Engine cowling installation
      • Baffles Installation
      • Exahaust Installation
      • Engine Installation
      • Fuel system
      • Electriacal system
      • Engine Mount
      • Fuel Tank
      • Nose wheel mount assembly
      • Nose wheel strut assembly
      • Tail wheel
      • Engine

This set of drawings are not complete or exhaustive

 Disclaimer: This item is  sold  for historical and reference Only.  These are either  ORIGINAL  or COPIES of  manuals and blueprints  used when these aircraft were in active duty,  now transferred into electronic format.  This manuals  and blueprints are  not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeler or aircraft buffs ....  For proprietary reasons we generally only provide civil manuals and blueprints on obsolete Aircrafts / Engines / Helicopter. The information is for reference only and we do not guarantee the completeness, accuracy or currency of any  manuals.

Reference herein to any specific commercial products by trade name, trademark, manufacturer, or otherwise, is not meant to imply or suggest any endorsement by, or affiliation with that manufacturer or supplier. All trade names, trademarks and manufacturer names are the property of their respective owners.

Delivered  : Download // Files Format : Adobe pdf // Compress Zipped in Rar to be uncopress with unrar http://www.rarlab.com/rar_add.htm
