Citabria Style Aircraft Blueprints Download

$28.85
Quantity:

Product Description

Plans to replicate the Citabria look of A/C. Included are drawings that will enable you to construct a look alike of the citabria aircraft. Original source of these dwgs are unknown.. ..  Dwgs show : Fuselage assy. truss / tube sizing / layout / dimensions / Tail assy. / Torque tube assy / pedals  / wing ribs "aluminum" / spars " wood and -limited aluminum spar detail shown "/ Struts / gear layout / fuselage bulkheads full size layouts & locations / wing layout / aileron & flap construction / Panel layout / Firewall / misc fittings and assemblies for construction /  Not shown is the engine mount but this is also available through Wag Aero as well *These are not factory dwgs. There are differences  Drawn in 1995 in title block 28 sheets total Approx size 2.5’ x 3’ sheet size Pics clearly show details  Dwgs are very clear and easy to understand. Most parts for the “look”  are now available through wag aero like cowls / gear / pre-formed parts etc that will work into such a project to make a similar looking aircraft.

This  Set of Engineering Drawings are not complete or exhaustive.



Disclaimer: This item is  sold  for historical and reference Only.  These are either  ORIGINAL  or COPIES of  manuals and blueprints  used when these aircraft were in active duty,  now transferred into electronic format.  This manuals  and blueprints are  not meant to be used for current update material for certification / repair, but make an excellent reference for the scholar, collector, modeler or aircraft buffs ....  For proprietary reasons we generally only provide civil manuals and blueprints on obsolete Aircrafts / Engines / Helicopter. The information is for reference only and we do not guarantee the completeness, accuracy or currency of any  manuals.

Reference herein to any specific commercial products by trade name, trademark, manufacturer, or otherwise, is not meant to imply or suggest any endorsement by, or affiliation with that manufacturer or supplier. All trade names, trademarks and manufacturer names are the property of their respective owners.

Delivered  : Download // Files Format : Adobe pdf // Compress Zipped in Rar to be uncopress with unrar http://www.rarlab.com/rar_add.htm
